MACHINE TOOLS

All machines and parts in the world are produced by machine tools

These machine tools produce the parts and components that make up various products by using the removal processing method, in which unnecessary parts are removed from the material. An example of the importance of machine tools is that they help to create parts for automobiles and trains that we use for daily transportation and also parts for home appliances that make our lives convenient. Every machine that exist in the world is directly or indirectly made by machine tools, and without them, our current life would not be possible at all. For this reason, they are also called " machines that makes machine or mother machines".

Getting to know machine tools!

Exhibit No.
M-26
Name
Profiling horizontal milling machine
Specification
Year of manufacture: 1961 / Bed type, No. 2 / 3-axis / Table dimensions 1250x450mm / (ST100 type)
Manufacturer
RIDGID (ブランド名。企業名ならRidge Tool CO

Exhibit No.
M-29
Name
Vertical milling machine
Specification
Year of manufacture: 1962 / Bed type, No. 1 / 2-axis program control / Table dimensions 900x240mm / (S-2 type)
Manufacturer
Matsuura Machinery Corporation

Exhibit No.
M-15
Name
Numerically controlled milling machine
Specification
Year of manufacture: 1971 / Knee type, No. 2 / 3-axis numerical control / Table dimensions 1350x310mm / (2MA/7060 type)
Manufacturer
Hitachi Seiko, Ltd.

Exhibit No.
M-16
Name
Numerically controlled milling machine
Specification
Year of manufacture: 1971 / Knee type, No. 2 / 3-axis numerical control / Table dimensions 1050x350mm / (KSNCP70 type)
Manufacturer
Makino Milling Machine Co., Ltd.

Exhibit No.
M-17
Name
Numerically controlled milling machine
Specification
Knee type, No. 2 / 3-axis numerical control / Table dimensions 1085x260 mm / (bed and column molded with resin concrete)
Manufacturer
Toyohashi University of Technology

Exhibit No.
M-10
Name
Milling machine
Specification
Knee type, No.2 / Table dimensions 1140x300mm
Manufacturer
Van Norman

Exhibit No.
G-33
Name
Cylindrical grinding machine
Specification
Year of manufacture: c.1920 / Swing over table 250mm / Distance between centers 400mm / Grinding wheel diameter 450mm
Manufacturer
Norton Grinding Company

Exhibit No.
G-28
Name
Cylindrical grinding machine
Specification
Year of manufacture: c.1930 / Swing over table 160mm / Distance between centers 250mm / Grinding wheel diameter 250mm / (HGP700 type)
Manufacturer
Carl Unger

Exhibit No.
G-9
Name
Cylindrical grinding machine
Specification
Year of manufacture: 1943 / Swing over table 250mm / Distance between centers 800mm / Grinding wheel diameter 400mm / (HGP700 type)
Manufacturer
Hokushin Electric Works Limited

Exhibit No.
G-32
Name
Cylindrical grinding machine
Specification
Year of manufacture: c.1960 / Swing over table 90mm / Distance between centers 150mm / Grinding wheel diameter 250mm
Manufacturer
Fortuna
